Category: Pneumatic Valves
Type: 5/2 Way Internally Piloted Acting Type Single Solenoid Valve
Model: 4V310-10
Coil: 24V AC, LED Light
Port Size: Air Inlet=Air Outlet=3/8″ BSPT
Effective area: 30mm2
Operating temperature range:-5~55℃
CV Value: 1.68
Coil power: 3VA
Working pressure range: 0.15~0.8MPa
Proof pressure: 1.05MPa
Voltage range: ±10%
Power consumption: AC:4.5W DC:3W
Insulation and protection: Class F.IP65
Wiring method: Lead and box
Frequency: 5/S
Response time: 50ms
Weight: 0.3kg
Packing List: 1* 4V310-10 5Ports2Position Single Solenoid Pneumatic Air Valve DC24V
